Doyono offers high-quality servos at a low price. This powerful, DC digital servo up to 35kgcm and DC motor has a aluminium copper gear and an aluminum housing. As a result, it ensures the right performance and thus also a lot of driving pleasure.
Features:
DC Digital Servo
Gears made of durable aluminium and copper
Lightweight aluminum housing
Waterproof
Operating Voltage: 6.0-7.4V
2µs dead band, 1520µs neutral point
360mm connection wire length
Technical Specifications:
Voltage: 6.0V 7.4V
Speed: 0.21sec 0.19sec
Torque: 29.0kgcm 35.0kgcm
Motor: DC
Gear: Aluminium / Copper
Bearing: yes, dual
Max. Travel: ~130° (bei 800: 2200µs)
Quiescent Current: 40mA @6.0V
Rated Current: 0.7A @6.0V
Blocking Current: 3.2A @6.0V
Dimensions: 40.7×20.5×38.9mm
Weight: 84.0g
Output Gear: 25T
Application: RC Crawler, 1/10 and 1/8 Off-Road, Electric Boats
